SentraRF110

Full-acrylic RF pedestal with Wi-Fi servicing and CCTV trigger, 1.8 m on 50 mm hard tags.

Request a quote RF 8.2 MHz · EAS gates

RF 8.2 MHzSentra

Sentra RF110

Overview

What it does

The RF110 is a full-acrylic RF pedestal for entrances where the gate has to look like part of the shopfit. At 8.2 MHz in dual configuration it reads a 4 × 4 cm label to 1.5 m, a 5 × 5 cm label to 1.6 m and a 50 mm hard tag to 1.8 m; as a mono post those become 1.0 m, 1.05 m and 1.15 m. The antenna is 155 × 37 × 10 cm on a 100–120 or 200–240 V supply at 50/60 Hz with a 2 m connection lead, and it accepts the 5003, 4201, 9600 or 9550 boards. Wi-Fi allows remote servicing and data extraction, and the CCTV link brings up the camera feed when the gate alarms.

Specifications

Manufacturer specifications for Sentra RF110
Brand	Sentra
Model	RF110P / RF110S
Material	Acrylic
Motherboard	5003 / 4201 / 9600 / 9550
Frequency	8.2 MHz
Antenna Size	155 × 37 × 10 cm
Input	100-120 / 200-240 V, 50/60 Hz
Connection Cable	2 meter
Detection (Dual - 4x4 RF Label)	Up to 1.5 meter
Detection (Dual - 5x5 RF Label)	Up to 1.6 meter
Detection (Dual - 50 mm Hard Tag)	Up to 1.8 meter
Detection (Mono - 4x4 RF Label)	Up to 1.0 meter
Detection (Mono - 5x5 RF Label)	Up to 1.05 meter
Detection (Mono - 50 mm Hard Tag)	Up to 1.15 meter
Operating frequency	8.2 MHz
Detection range — 40x40 mm soft label	1.6 m
Detection range — 50x50 mm soft label	1.7 m
Detection range — R50 hard tag	1.9 m
Detection mode	Transmitter + receiver (dual antenna pair)
Dimensions (H x W x D)	155 x 37 x 10 cm
Frame material	High-grade acrylic
Colour	Transparent
Input voltage	110 V / 220 V AC, 50/60 Hz
Tuning / remote support	Software + WiFi tuning
Certification	CE Compliant
Detection range (dual)	soft tag 5.25 feet · hard tag 6 feet
Detection range (mono)	soft tag 3.5 feet · hard tag 4 feet
Configuration	Supplied as primary (master) or secondary (slave) antenna

Where it earns its keep

Premium retail entrances on RF tagging
Head offices pulling alarm data remotely
Sites linking EAS alarms to CCTV review

Figures above are the manufacturer's published specifications. The detection aisle, sensitivity and tag mix that work on your floor are confirmed during the site survey.
