EAS gates & pedestals

CheckpointAMF10

Light 5.6 kg ABS AM pedestal at 58 kHz for narrow single-door shop entrances.

Request a quote AM 58 kHz · EAS gates

AM 58 kHzCheckpoint

Checkpoint AMF10

Overview

What it does

The AMF10 is the entry ABS pedestal in the Checkpoint AM line, at 5.6 kg net per piece — light enough for one fitter to stand up and bolt down. It runs 58 kHz and detects DR labels at 1.6–1.8 m, drawing 25 W per antenna from 110–220 V. A master unit will carry up to two slaves with no external controller, and each antenna can be commissioned as transceiver, transmitter or receiver. Jammer detection and on-board oscilloscope diagnostics are included, which matters where the shop has no technician of its own.

Specifications

Manufacturer specifications for Checkpoint AMF10
Brand	Checkpoint
Model	AMF10P / AMF10S
Material	ABS
Frame colour	White
Frequency	58 kHz
Net weight	5.6 kg (per piece)
Gross weight	7 kg (per piece)
DR Label Detection	1.6 m - 1.8 m
Power Consumption	25 W (per antenna)
Operating Voltage	110-220 V
Country of Technology	Europe
Country of Origin	China
Detection range (dual)	soft tag 4.5 feet · hard tag 5.5 feet
Detection range (mono)	soft tag 2 feet · hard tag 2.5 feet
Configuration	Supplied as primary (master) or secondary (slave) antenna

Where it earns its keep

Single-door shops and pharmacies
A first EAS installation on a tight budget
Chains needing one repeatable, quick-to-fit gate

Figures above are the manufacturer's published specifications. The detection aisle, sensitivity and tag mix that work on your floor are confirmed during the site survey.
