SentraRF108

Acrylic 8.2 MHz RF pedestal reading 3 × 3 cm labels to 1.5 m, large square tags to 2.0 m.

Request a quote RF 8.2 MHz · EAS gates

RF 8.2 MHzSentra

Sentra RF108

Overview

What it does

The RF108 is a slim acrylic RF pedestal at 8.2 MHz, 1580 × 360 × 20 mm and 18 kg net. A 3 × 3 cm RF label reads at 1.2–1.5 m and a large square tag at 1.5–2.0 m, so label choice sets the door width it can cover. It ships with the TCF board, which is straightforward to tune. Power varies with configuration — 25 W dual, 30 W mono and 40 W in a 1TX+2RX three-post run — from 110–220 V with a 24 V 2 A output.

Specifications

Manufacturer specifications for Sentra RF108
Brand	Sentra
Model	RF108P / RF108S
Material	Acrylic Frame
Colour	Transparent
Frequency	8.2 MHz
RF Label 3*3 Detection	1.2-1.5 m
RF Large Square Tag	1.5-2.0 m
Dimensions	1580 × 360 × 20 mm
Net weight	18 kg
Gross weight	22 kg
Operating Voltage	110 - 220 V
Output	24 V 2A
Work Rate	Mono 30 W, Dual 25 W, 1TX+2RX 40 W
Operating frequency	8.2 MHz
Frame material	Acrylic
Base cover material	ABS
Frame colour	Transparent
Base cover colour	Silver
Dimensions (per antenna)	1600×380×110 mm
Packaging dimensions	1640×488×145 mm
Power consumption (per antenna)	10 W
Detection range (dual)	soft tag 5.25 feet · hard tag 6.5 feet
Detection range (mono)	soft tag 2.5 feet · hard tag 3.5 feet
Configuration	Supplied as primary (master) or secondary (slave) antenna

Where it earns its keep

Stores standardised on small 3 × 3 cm RF labels
Three-post runs across a wide RF-protected exit
Retailers who need few false alarms on a busy door

Figures above are the manufacturer's published specifications. The detection aisle, sensitivity and tag mix that work on your floor are confirmed during the site survey.
