EAS gates & pedestals

SentraRF107

8.2 MHz acrylic RF pedestal at 10 W, hard tags to 2.4 m on the dual board.

Request a quote RF 8.2 MHz · EAS gates

RF 8.2 MHzSentra

Sentra RF107

Overview

What it does

The RF107 is an acrylic RF pedestal running 8.2 MHz, at 1585 × 360 × 125 mm and 16 kg net. Detection depends on the board fitted: the dual 95100 board reads soft labels at 1.4–1.5 m and hard tags at 2.4 m, while mono boards give 0.7 m and 1.1 m on the M98 or 1.0 m and 1.4 m on the M95. Power is 10 W per antenna on 110–220 V — low enough that a small shop will not see it on the bill. Integrated colour LEDs can be left on permanently as a deterrent or set to light only on alarm.

Specifications

Manufacturer specifications for Sentra RF107
Brand	Sentra
Model	RF107P / RF107S
Material	Acrylic
Frame colour	Transparent
Frequency	8.2 MHz
Dimensions	1585 × 360 × 125 mm
Net weight	16 kg
Gross weight	19.5 kg
Operating Voltage	110-220 V
Work Rate	10 W (per antenna)
Detection (Dual/95100 - Soft Label)	1.4-1.5 m
Detection (Dual/95100 - Hard Tag)	2.4 m
Detection (Mono/M98 - Soft Label)	0.7 m
Detection (Mono/M98 - Hard Tag)	1.1 m
Detection (Mono/M95 - Soft Label)	1.0 m
Detection (Mono/M95 - Hard Tag)	1.4 m
Operating frequency	8.2 MHz
Panel dimensions (per antenna)	1585 × 360 × 125 mm
Packaging dimensions	1640 × 488 × 145 mm
Net / gross weight	16 kg/19.5 kg
Power draw per antenna	10 W
Colour	Frame: Transparent; Base cover: Black
Detection range (dual)	soft tag 5 feet · hard tag 8 feet
Detection range (mono)	soft tag 3.3 feet · hard tag 4.5 feet
Configuration	Supplied as primary (master) or secondary (slave) antenna

Where it earns its keep

RF-tagged shops that want a lit gate
Buyers choosing between mono and dual on cost
Low-power installations in small units

Figures above are the manufacturer's published specifications. The detection aisle, sensitivity and tag mix that work on your floor are confirmed during the site survey.
