EAS gates & pedestals

SentraAM115

Rimless acrylic AM pedestal with app-based remote tuning and mono, dual or trio setup.

Request a quote AM 58 kHz · EAS gates

AM 58 kHzSentra

Sentra AM115

Overview

What it does

The AM115 is a rimless transparent acrylic pedestal aimed at boutiques and clothing stores where a framed gate would spoil the front. It reads DR labels at 1.7 m and hard tags at 2.1 m at 58 kHz, and can be commissioned as a mono, dual or trio run. Tuning is done from a PC browser or a mobile app rather than at the board, which shortens service calls, and the unit links to CCTV and carries customisable LED lighting. It weighs 25 kg net per post and draws 100 W total, 25 W per antenna, on 110–220 V.

Specifications

Manufacturer specifications for Sentra AM115
Brand	Sentra
Model	AM115P / AM115S
Material	Acrylic
Frame colour	Transparent
Frequency	58 kHz
DR Label Detection	1.7 m
Hard Tag Detection	2.1 m
Net weight	25 kg
Gross weight	30 kg
Operating Voltage	110-220 V
Power Consumption	100 W
Work Rate (Per Antenna)	25 W
Detection range (dual)	soft tag 6 feet · hard tag 9 feet
Detection range (mono)	soft tag 3 feet · hard tag 4.5 feet
Configuration	Supplied as primary (master) or secondary (slave) antenna

Where it earns its keep

Boutiques and clothing brands with a designed shopfront
Multi-branch chains servicing gates remotely
Three-post runs across a wide entrance

Figures above are the manufacturer's published specifications. The detection aisle, sensitivity and tag mix that work on your floor are confirmed during the site survey.
