SentraAM105

Wide-exit acrylic AM pedestal with 2.2–3.2 m detection from a 520 mm panel.

Request a quote AM 58 kHz · EAS gates

AM 58 kHzSentra

Sentra AM105

Overview

What it does

The AM105 is the long-reach acrylic pedestal in the Sentra AM range, detecting from 2.2 m to 3.2 m depending on the tag, from a 1500 × 520 × 25 mm panel. The extra width over the AM104 is what buys the reach, so allow for it in the door plan. It runs 58 kHz on the standard acousto-magnetic tag and label estate. Specify it where the entrance is genuinely wide and a third pedestal is not wanted.

Specifications

Manufacturer specifications for Sentra AM105
Brand	Sentra
Model	AM105P / AM105S
Colour	White
Frequency	58 kHz
Antenna Material	Acrylic
Detection Range	2.2 m - 3.2 m
Dimensions	1500 × 520 × 25 mm
Technology	AM (acousto-magnetic)
Material	Acrylic
Detection range (dual)	soft tag 7 feet · hard tag 10 feet
Detection range (mono)	soft tag 3.5 feet · hard tag 5 feet
Configuration	Supplied as primary (master) or secondary (slave) antenna

Where it earns its keep

Wide single-span entrances
Stores wanting two posts instead of three
Anchor units in Dhaka shopping centres

Figures above are the manufacturer's published specifications. The detection aisle, sensitivity and tag mix that work on your floor are confirmed during the site survey.
