EAS gates & pedestals

SentraAM103

Acrylic AM pedestal with Wi-Fi servicing and CCTV trigger, 2.0 m detection in dual mode.

Request a quote AM 58 kHz · EAS gates

AM 58 kHzSentra

Sentra AM103

Overview

What it does

The AM103 is an acrylic AM pedestal built around the A2000 board, with Wi-Fi for remote tuning and a CCTV link that can pull up the camera feed when the gate alarms. In dual configuration it reads DR labels and 46 mm pencil tags up to 2.0 m; as a mono post both fall to 1.0 m. The antenna is 155 × 35 × 12 cm on a 100–120 or 200–240 Vac supply at 50/60 Hz, with a 2.5 m connection cable. Specify it where the shop wants a clear gate and head office wants the alarms logged.

Specifications

Manufacturer specifications for Sentra AM103
Brand	Sentra
Model	AM103P / AM103S
Material	Acrylic
Frequency	58 kHz
Antenna Size	155 × 35 × 12 cm
Input	100-120 / 200-240 VAC , 50/60 Hz
Connection Cable	2.5 meter
Detection (Dual - DR Label)	Up to 2.0 meter
Detection (Dual - 46mm Pencil)	Up to 2.0 meter
Detection (Mono - DR Label)	Up to 1.0 meter
Detection (Mono - 46mm Pencil)	Up to 1.0 meter
Detection range (dual)	soft tag 6 feet · hard tag 6 feet
Detection range (mono)	soft tag 3 feet · hard tag 3 feet
Configuration	Supplied as primary (master) or secondary (slave) antenna

Where it earns its keep

Boutiques reporting to a head-office loss-prevention team
Sites where alarms must trigger CCTV review
Chains that service gates remotely rather than by van

Figures above are the manufacturer's published specifications. The detection aisle, sensitivity and tag mix that work on your floor are confirmed during the site survey.
