EAS gates & pedestals

GuardiaAM160

ABS AM pedestal on the Ultra board, 1.8–2.8 m detection at only ≤15 W.

Request a quote AM 58 kHz · EAS gates

AM 58 kHzGuardia

Guardia AM160

Overview

What it does

The AM160 is the higher-reach ABS pedestal in the Guardia AM range, running the Ultra board at 58 kHz. Detection is 1.8 m to 2.8 m depending on the tag, from a 1545 × 500 × 130 mm frame drawing ≤15 W on 110–230 V at 50–60 Hz. It can be set up as a TX+RX pair or as a single mono post. Where the AM157 and AM158 start at 0.9 m, this board holds a floor of 1.8 m, so it is the one to specify when the doorway is genuinely wide and the tag mix is varied.

Specifications

Manufacturer specifications for Guardia AM160
Brand	Guardia
Model	AM160P / AM160S
Colour	Grey
Frequency	58 kHz
Detection Range	1.8-2.8M (depends on tag)
Material	ABS plastic
Dimensions	1545 × 500 × 130 mm
Rated Power	≤15 W
Operating Voltage	110-230 V, 50-60 Hz
Technology Source	Ultra Board
Working Mode	TX+RX OR MONO
Packing Size	1620 × 590 × 250 mm (2pcs/ctn)
Detection range (dual)	soft tag 6.5 feet · hard tag 9 feet
Detection range (mono)	soft tag 3 feet · hard tag 4.5 feet
Configuration	Supplied as primary (master) or secondary (slave) antenna

Where it earns its keep

Wide entrances with a mixed tag and label estate
Supermarkets replacing an under-performing gate
Low-power installs on a constrained supply

Figures above are the manufacturer's published specifications. The detection aisle, sensitivity and tag mix that work on your floor are confirmed during the site survey.

Part of a system

EAS Anti-Theft Gates

The pedestals at your door are the single most visible loss-prevention decision you will make. They have to catch what leaves unpaid, ignore what does not, and look like they belong in your store.

Read the EAS gates guide
