Guardia AM158

Overview

What it does

The AM158 is the metal-base build of Guardia's 58 kHz acousto-magnetic pedestal, for entrances where a plastic base gets kicked. It works as a TX+RX pair or as a single mono post, with detection between 0.9 m and 2.8 m depending on the tag. Rated power is ≤15 W on 110–230 V at 50–60 Hz, running the A1500 board. The controller is not included, so budget for one separately unless there is a spare on site.

Specifications

Manufacturer specifications for Guardia AM158
Brand	Guardia
Model	AM158P / AM158S
Colour	Grey
Frequency	58 kHz
Detection Range	0.9-2.8M (depends on tag)
Material	ABS plastic
Dimensions	1545 × 500 × 30 mm
Rated Power	≤15 W
Operating Voltage	110-230 V, 50-60 Hz
Working Mode	TX+RX OR MONO
Technology Source	A1500
Packing Size	1620590250 mm (2pcs/ctn)
Detection range (dual)	soft tag 6.5 feet · hard tag 9 feet
Detection range (mono)	soft tag 3 feet · hard tag 4.5 feet
Configuration	Supplied as primary (master) or secondary (slave) antenna

Where it earns its keep

High-traffic entrances where bases get knocked
Sites already holding a spare controller
Wide doorways run as a TX+RX pair

Figures above are the manufacturer's published specifications. The detection aisle, sensitivity and tag mix that work on your floor are confirmed during the site survey.
