CheckpointEvolve P20 Mono

Single-pedestal RF gate for narrow doorways, using the slim Evolve P20 body.

Request a quote RF 8.2 MHz · EAS gates

RF 8.2 MHzCheckpoint

Checkpoint Evolve P20 Mono

Overview

What it does

The Evolve P20 Mono is the single-pedestal build of the same slim RF antenna, transmitting and receiving from one post. The catalogue rates it at roughly 3 ft of aisle for soft labels and 3.5 ft for hard tags, so it suits a single-leaf door rather than a wide entrance. It runs the same 7.9 to 8.5 MHz sweep and the same 25 W per antenna draw as the pair. One pedestal means one floor fixing and one cable run, which is often the deciding factor in a leased unit.

Specifications

Manufacturer specifications for Checkpoint Evolve P20 Mono
Brand	Checkpoint
Model	Evolve P20 Mono
Material	ABS
Frame colour	White
Frequency	7.9 to 8.5 MHz
Net weight	5.6 kg (per piece)
Gross weight	7 kg (per piece)
DR Label Detection	1.6 m - 1.8 m
Power Consumption	25 W (per antenna)
Operating Voltage	110-220 V
Detection range (dual)	soft tag 6 feet · hard tag 7 feet
Detection range (mono)	soft tag 3 feet · hard tag 3.5 feet
Configuration	Single-pedestal (mono) unit

Where it earns its keep

Single-leaf doors and staff or side exits
Small shops with one narrow entrance
Landlord restrictions on floor fixings

Figures above are the manufacturer's published specifications. The detection aisle, sensitivity and tag mix that work on your floor are confirmed during the site survey.
