Alarms & metal detection

GuardiaG51 Alarm Panel

Guardia's alarm hub: pairs door, motion, smoke and gas detectors and reports over Wi-Fi or GSM.

Request a quote Wireless · Alarms & detectors

WirelessGuardia

Guardia G51 Alarm Panel

Overview

What it does

The G51 is the controller for a wireless alarm system - door and window contacts, PIR detectors, smoke, heat and gas detectors, remote fobs and SOS buttons all pair back to it over 433 MHz. It reports through Wi-Fi (802.11 b/g/n, 2.4 GHz, WEP / WPA-PSK / WPA2-PSK) and GSM on 850/900/1800/1900 MHz, is armed and programmed from a phone app, and shows its state on a five-colour LED. Mains input is AC 100-240 V with a 3.7 V 800 mAh battery behind it, and the built-in siren gives 80 dB at 1 m. Pairing range is quoted in open air at >=400 m to a PIR detector, >=300 m to a siren, >=200 m to a door sensor and >=100 m to a remote - expect considerably less through a concrete shop building, so site the panel centrally rather than in a back office.

Specifications

Manufacturer specifications for Guardia G51 Alarm Panel
Brand	Guardia
Model	G51
Power Supply	AC100 V~240 V
Battery	3.7 V/800mAh
Built-in Siren	80dB (within 1M)
Wireless Frequency	433 MHz
GSM Frequencies	850 MHz, 900 MHz, 1800 MHz, 1900 MHz
WiFi Standard	802.11 b/g/n (2.4G)
WiFi Encryption	WEP / WAP-PSK / WPA2-PSK
Networking Protocol	IPv4, TCP/UDP/HTTP
Dimensions	141 × 140 × 25 mm
Wireless Range	PIR detector : ≥ 400 m;
Door sensor	≥ 200 m;
Remote	≥ 100 m;
Siren	≥ 300 m;
Power	AC100 V~240 V
Wireless working frequency	433 MHz
GSM working frequency	850 MHz, 900 MHz, 1800 MHz, 1900 MHz
GSM emitting power	≤2 W(850/900 MHz), ≤1 W(1800/1900 MHz)
WiFi frequency	2.4G
WiFi security	WEP / WAP-PSK / WPA2-PSK
Network protocols	IPv4, TCP/UDP/HTTP
Working temperature	10°C- +50°C
Humidity	40% ~ 70%
Height	25 mm
Width	140 mm
Length	141 mm
Wireless range, siren to alarm panel	≥300 m (in the open area)
Mobile app	Android or IOS APP available
Colours	Black, White

Where it earns its keep

Shops and showrooms armed out of hours
Intrusion, fire and gas cover managed on one panel
Owners who want app control instead of a monitoring contract
Multi-room premises with detectors spread across floors

Figures above are the manufacturer's published specifications. The detection aisle, sensitivity and tag mix that work on your floor are confirmed during the site survey.
